Feral Squirrel 72VDC 100A Single Channel Full H-Bridge Brushed Speed Controller

$199.00
Limit 1 per order
Sold Out

  • Single channel brushed motor driver (Specifically designed for multiple 550, 775, 887, 895, and 997 Brushed DC motors in parallel)

  • 12 - 85VDC input voltage (Up to 72V 20S (20 Series Cells) Lithium Ion battery packs (72V / 24S LiFePo4 packs will exceed the voltage limit)

  • 100A continuous output

    • 200A Burst Limit (2 seconds)

    • 350A Short Circuit Limit (20 us)

  • Has been tested up to 8KW with 72V Li-ion battery pack

  • Wi-fi Access Point for configuration, monitoring, and Diagnostics

  • Variable Throttle Input

  • Variable Brake Input

  • 4 Configurable inputs

    • Two forward speed limits and one reverse speed limit

    • Launch Control

    • Boost function (Replaced high speed)

    • Smart inputs can be connected to B- to activate or connected to any voltage between 12V and 85V

  • Supports auto regenerative braking, single pedal mode

  • 12VDC 8A accessory output (Regulates to 12VDC when input is over 12VDC, tracks input voltage when under 12VDC)

  • RC Receiver Input (Standard hobby grade remote receivers that work on 3.3V)

  • 2 general purpose outputs (for use with 12V supply)

  • +12V Fan output, PWM fan output, can be controlled based on controller internal temp

  • Single channel brushed motor driver (Specifically designed for multiple 550, 775, 887, 895, and 997 Brushed DC motors in parallel)

  • 12 - 85VDC input voltage (Up to 72V 20S (20 Series Cells) Lithium Ion battery packs (72V / 24S LiFePo4 packs will exceed the voltage limit)

  • 100A continuous output

    • 200A Burst Limit (2 seconds)

    • 350A Short Circuit Limit (20 us)

  • Has been tested up to 8KW with 72V Li-ion battery pack

  • Wi-fi Access Point for configuration, monitoring, and Diagnostics

  • Variable Throttle Input

  • Variable Brake Input

  • 4 Configurable inputs

    • Two forward speed limits and one reverse speed limit

    • Launch Control

    • Boost function (Replaced high speed)

    • Smart inputs can be connected to B- to activate or connected to any voltage between 12V and 85V

  • Supports auto regenerative braking, single pedal mode

  • 12VDC 8A accessory output (Regulates to 12VDC when input is over 12VDC, tracks input voltage when under 12VDC)

  • RC Receiver Input (Standard hobby grade remote receivers that work on 3.3V)

  • 2 general purpose outputs (for use with 12V supply)

  • +12V Fan output, PWM fan output, can be controlled based on controller internal temp

The apex predator has escaped the workshop.

Meet the Feral Squirrel - Peanut Workshop’s most aggressive brushed motor controller yet.

Built for the nutcases who looked at a Speedy Squirrel and said, “Yeah… but what if we fed it more volts?”

Go Feral

Designed specifically for high-power multi-motor Power Wheels and ride-on builds, the Feral Squirrel is engineered to drive multiple 550, 775, 887, 895, and 997 brushed DC motors in parallel without flinching.

A brutally capable single-channel brushed motor driver supporting:

12-85vdc input

Up to 72V 20S lithium-ion battery packs

100a continuous output

200a burst current (2 seconds)

350A short-circuit protection

Tested at up to 8KW on a 72V lithium setup.

This squirrel doesn’t just climb trees — it launches out of them.

The Feral Squirrel brings modern tuning and diagnostics to the brushed world through its built-in Wi-Fi access point, allowing wireless configuration, monitoring, and diagnostics directly from your phone or device. No hunting for cables. No cracking open the enclosure. Just connect and tune.

Wireless tuning. real control.

Driver Control

Performance

Need custom controls? The Feral Squirrel includes four configurable smart inputs that can be activated through B- or any voltage from 12V–85V, making integration into advanced builds incredibly flexible.

hardware support includes:

  • 12V 8A accessory output

  • RC receiver input for hobby-grade 3.3V remote systems

  • Two general-purpose outputs

  • Dedicated +12V fan output

  • PWM-controlled fan output based on controller temperature

Translation?
We fed the squirrel more volts. This is the result.

It’s designed for the builders who smell burning rubber and think, “Needs more voltage.”

The ones always finding room for one more battery and one more motor.

The ones pushing brushed performance to the next level.

The Feral Squirrel is not a toy-grade controller pretending to be performance hardware.

It’s a full-send brushed ESC built for serious builders who are ready to go completely nuts.
